Frame |
Aluminium FullSuspension, 140mm Travel |
Wheelsize |
27.5“/584mm, 29"/622mm |
Fork |
RockShox 35 Silver R, Coil, 140 mm, tapered |
Damper |
SR SUNTOUR Raidon R, Air, 230x60 mm |
Drive Unit |
Yamaha PW-X2, 250 W, 80 Nm |
Battery |
Simplo, 630 Wh, 36 V |
Charger |
Simplo rapid charger, 4 A |
Display |
Yamaha Display A, LCD-Display, Micro-USB |
Brake, rear |
Tektro HD-M745, 4-piston, Hydraulic disc brake |
Brake disc, rear |
Tektro TR53, 203 mm, 6-hole |
Brake, front |
Tektro HD-M745, 4-piston, Hydraulic disc brake |
Brake disc, rear |
Tektro TR53, 203 mm, 6-hole |
Brake levers |
Aluminium, Brake lever, adjustable, 2-finger |
Derailleur/Gears |
Shimano Deore LG, RD-M5130, Shadow Plus, 10-S |
Gear levers |
Shimano Deore, SL-M5130, Rapidfire Plus |
Chain |
Shimano CN-LG500 |
Chainring |
R Raymon, Narrow Wide, 38 T |
Cassette |
Shimano CS-LG400, 11-43 T |
Rear Wheel |
Rim: Mach 1 TRUCKY 30, With eyelets, Tubeless ready / Hub: R Raymon DA210R, 6-hole, 12x148 mm, thru axle, HG |
Front Wheel |
Rim: Mach 1 TRUCKY 30, With eyelets, Tubeless ready / Hub: R Raymon DA210F, 6-hole, 15x110 mm, thru axle |
Tyre, front |
Continental Trail King, 60-622, 29x2.4 |
Tyre, rear |
Continental Trail King, 65-584, 27.5x2.6 |
Grips |
R Raymon MTB, Lock-on grips |
Bar |
R Raymon Riser 31.8 mm, 780 mm, Sweep: 9 °, Rise: 15 mm |
Saddle |
R Raymon MTB |
Seatpost |
R Raymon, 31.6 mm, Dropper post |
Stem |
R Raymon 31.8, 0 °, Ahead |
Pedals |
R Raymon, aluminum |
Max. total weight |
130 kg |
